Audison AF C8.14 bit 14-Kanal DSP + 800W 8-Kanal Verstärker - FORZA
Dear Audison enthusiast,
We are pleased to inform you that the new Audison Forza line is taking off. This is the most innovative and ambitious project in the history of the brand.
Share:
FacebookE-MailTwitterWhatsAppSkypeWeChat
Zubehöre
B-CON
Audison B-CON ist der erste Bluetooth 5.0®-Player, der speziell für den Einsatz in Fahrzeugen entwickelt wurde und von der Japan Audio Society die Zertifizierung „Hi-Res Audio Wireless“ erhalten hat. B-CON ist die ideale Wahl wenn die Hi-Res Audio Player (Fioo, Sony Walkman,…) oder ein Android/Apple Smartphone der neuesten Generation nutzen.
B-CON ist kompatibel mit allen Audio Formaten und erreicht ein Maximum an Performance bei nicht reduziertem BT Streaming (max 96 kHz / 24 bit nur mit Android LDAC Geräten) von gespeichertem Musikmaterial oder Diensten wie Tidal, Qobuz….etc.
Read More
DRC AC
DRC AC enables the primary system control: master volume, sub volume, source select, memory select, global eq.
F4IN
F4IN extension card adds four additional analog input channels
F2O
F2O extension card provides an additional Coaxial SPDIF or a second Toslink SPDIF input.
PRE-IN CABLE - PROVIDED
Eight stereo RCAs interconnection to connect Forza bit amplifier with after-market sources with PRE-OUT outputs provided with Forza amplifiers.
SPEAKERS OUT CABLE
Provided cable with eight pairs of labeled cables to connect the speakers to the AF M8.14 bit and AF C8.14 bit.
SPEAKER-IN CABLE - PROVIDED
Provided cable with 8 pairs of labeled wires to connect Forza bit amplifiers bit with the high-level output of OEM sources.
DSP OUT CABLE 6CH - PROVIDED
6 channels DSP output cable to connect Forza bit amplifier to Forza D amplifier.
USB CABLE - PROVIDED
USB cable to connect Forza bit amplifiers to PC.
FORZA INSTALL KIT - PROVIDED
FORZA CONTROL CABLE - PROVIDED
Provided control interconnection to control memory selection and remote power-on.
C2O
EINSATZBEREICH:
Die C2O-Schnittstelle wandelt die vom koaxialen Digitaleingang und vom analogen AUX-IN kommenden Signale in ein optisches digitales TOSLINK-Ausgangssignal (bis zu 24 Bit / 192 kHz) um.
Der Wandler ermöglicht die Integration der neuen tragbaren Hi-Res-Audio Geräte mit einem koaxialen Digitalausgang (75 Ω) und Smartphones mit einem analogen Ausgang über 3,5-mm Klinke Buchse (auch 4-polig) in unsere Audison-Prozessoren die über einen optischen Digitaleingang mit passender Auflösung verfügen.
Produkteigenschaft
Enjoy the improved audio performance of the latest generation Audison D-Class technology.
Maximum versatility thanks to the bridging option for each pair of channels.
Forza amplifiers have two independent power supplies: the audio amplifier power supply is loosely regulated, which allows superior dynamic performance. The DSP power supply is stiffly regulated, which maintains DSP microprocessor operation even during lower-voltage transient states (i.e., start/stop operation).
Native DSP working at 24 bit/96 kHz and an extended audio band up to 40 kHz.
Pure digital signal transfer with a resolution up to 24bit/96 kHz.
Quick I/O Configuration speeds up system definition and signal routing.
When connected with Audison B-CON hi-res Bluetooth receiver, this feature manages the Master Volume of the Forza amp thus ensuring full dynamic range signal at the input.
iDatalink Maestro AR native support for a total integration with OEM infotainment.
Equipped with eight analog inputs, to support total connectivity even with the most complex OEM systems.
Electrical Signal Analysis ensures proper integration and correction for each input channel.
Automatically sums and reverses OEM equalization.
Input delay compensation of time-delayed factory outputs prior to signal summing.
Allows left and right inputs to match in phase before tuning, even if OEM phase processing has been used.
Universal Speaker Simulator technology on high-level inputs for maximum compatibility with any type of Head-Unit OEM Source.
Next-generation bit Drive software platform - developed for this family of products - simplifies every control and function.
14 DSP-processed output channels for a total control.
6 native pre-out channels for maximum versatility.
The acoustic analysis integrates the response graph into the equalizer display ensuring efficient tuning and great sound, compatible with any 24-bit USB microphone.
The electrical analysis integrates the response graph into the input equalizer display, ensuring efficient tuning.
